Tenoning width & depth is adjustable within specified limits, The tenoning axis can be horizontal, vertical or 45° by changing the data in PLC unit.
Due to PLC Programmable device, the movable cutter runs as per data & design. This process is more stable because only cutter is turning during the process.
Due to PLc programmable device, the moveable cutter runs as per data & profile.The processing is more stable, because of only the cutter is moving.
The double table design enhances the productivity. Pneumatic clamping for better gripping.
| Model No | Unit |
J-941 |
| Max. quadrate tenoning size | mm |
140 x 80 |
| Max.horizontal tenoning width | mm |
430 / 140 |
| Max.tenoning width | mm |
80 |
| Max.round tenoning diameter | mm |
80 |
| Spindle speed | rpm |
6700 |
| Motor power | kW |
5.5 |
